321 Stainless Steel Pipe / 1.4541 SS tubing UNS S32100 piping
Titanium in 321 stainless steel pipe exists as a stabilizing element, but it is also a heat-resistant steel grade, which is much better than 316L material at high temperatures. 321 stainless steel pipe has good wear resistance in organic and inorganic acids of different concentrations and temperatures, especially in oxidizing media, and is used to manufacture linings and conveying pipelines for wear-resistant acid containers and wear-resistant equipment.
321 Stainless Steel Pipe produced under specification ASTM A312 has been designed to resist inter-granular corrosion, especially in high temperature settings. 321 SS Piping has good toughness properties even at lower temperatures. 321 material is also called 1.4541 in DIN Germany standard and UNS S32100 Stainless Steel.

Product sellable. Not available in the online Store - please contact us.

Contact us
The pictures shown are for reference only.
SPECIFICATION
PRODUCT DISPLAY
MATERIAL / DOCUMENT DOWNLOAD

Specification of ASTM A312 TP321

Name & Usage321 Stainless Steel Pipe (1.4541 SS tubing UNS S32100 piping)
ShapesRound, Rectangular, Square, Hydraulic, Straight, "U" Shape, Coiled, Honed Tubes, Pan Cake Coils
Manufacturing TypeSeamless / ERW / Welded / Fabricated / CDW / CDS / DOM / CEW / 100% X Ray Welded 321 Tubing
Delivery ConditionAnnealed and Pickled (AP), Polished, Bright Annealed (BA), Cold Drawn, MF
Surface FinishBA, 2B, No.4, No.1, No.3, No.8, 8K, HL, 2D, 1D, Mirror Polished, 180G, 320G, 400G Satin/ Hairline, 400G, 500G, 600G or 800G Mirror finish Stainless steel 321 Tubing
Thickness RangeSCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXH, SCH XXS, SCH XS
StandardASTM, ASME,DIN, EN, SUS, JIS, AS, GOST for 321 Stainless Steel Pipe
Relevant StandardASTM A213, ASTM A312, ASTM A269, ASTM A778, ASTM A554, ASTM A249, ASTM A269, ASTM A270, ASTM A789, ASME SB 677, DIN 17456, DIN17457, DIN 17459, JIS G3459, JIS G3463, GOST9941, EN10216, BS3605 these standard all for 321Stainless Steel Pipe


ASTM A312 TP321 Material in stock

SA 312 TP 321 3 Inch TubeStainless Steel UNS S32100 Dairy Tube
A312 GR TP321 Square TubeSS UNS S32100 TP321 ERW Tube
A312 TP 321 Seamless TubeAustenitic SS TP321 Polished Tube
TP 321 Stainless Steel Hollow TubeASTM A 312 TP 321 Stainless Steel Schedule 80 Tube
ASTM A312 SS 321 Rectangular TubeASTM A312 GR TP321 Schedule 10 Tube
Austenitic Stainless Steel 321 Round TubeA312 Stainless Steel 321 thick wall polished Tube
ASTM A312 TP321 Exhaust TubeSS UNS S32100 SHS & RHS Tube
A312 TP321 Schedule 40 TubeTP 321 Stainless Steel DIN 1.4541 Water Tube
1.4541 Stainless Steel 321 C Class TubeSA312 321 Stainless Steel Threaded Tube



Chemical Composition:

CSiMnCrNiSP
≤ 0.08≤ 0.75≤ 2.017.0~19.09.0~12.0≤ 0.03≤ 0.045


Mechanical Properties:

Tensile Strength Kb (MPa)Yield Strength σ0.2 (MPa)Elongation D5 (%)Hardness
≥520≥205≥ 40≤ 187HB;≤ 90HRB;≤ 200HV


Physical Performance:

Density(g/cm³)Modulus of Elasticity(Gpa)Coefficient of Thermal Expansion(10-6/°C)Coefficient of Thermal Conductivity(W/m*K)Resistivity(ΜΩ. cm)
7.9219316.61672
